Boiler Settings
29th Dec 2025
- Top cylinder 50° (controls final shutdown if boiler is out and no heat stored)
- Top of dual stat (burner control) 82°
- Bottom of dual stat below 70° return heat pump from accum
- Overtemp pump start above 79° boost heat flow to accum
Both accumulator storage tank pumps reversed direction, System shut down changed to 50°
26th nov 2025
first lit on 24th
flow 1 1/2 turns opened to UFH in airing cupboard
Boiler circ pump (Laddomat) at no 2 after freeing from sludge starts about 60deg
- Top cylinder 58° (controls final shutdown if boiler is out and no heat stored)
- Top of dual stat (burner control) 83°
- Bottom of dual stat below 74° return heat pump from accum
- Overtemp pump start above 80° boost heat flow to accum
24th nov 2024
LAE MTC12 instructions ( to alter bottom one, alter top first , then reset)
Increased return heat stat from 62 to 70
Gas valve shut off up to 43
3 port valve actuator failed and removed
flow restricted to UFH in airing cupboard
4th Dec 2023
Stats needed for new box:
- Top cylinder 51° (controls final shutdown if boiler is out and no heat stored)
- Top of dual stat (burner control) 82°
- Bottom of dual stat below 62° return heat pump from accum
- Overtemp pump start above 80° boost heat flow to accum
21st March 2023
End of 2022 logs, last week
House set -back 15 ° on Gas 17° on wood
20th Feb
House 3 port valve and gas control set down to 36°
- Top cylinder 51° (controls final shutdown if boiler is out and no heat stored)
- Top of dual stat (burner control) 82°
- Bottom of dual stat below 62° return heat from accum
- Bottom cyl
- Overtemp pump start (Top left stat) above 80° boost heat pump to accum
- Mid cylinder (bottom right stat) stoke alarm disconnected
30 Jan 2023
disc usage 6,199.83
House 3 port valve and gas control set down to 36°
- Top cylinder 51° (controls final shutdown if boiler is out and no heat stored)
- Top of dual stat (burner control) 80°
- Bottom of dual stat below 62° return heat from accum
- Bottom cyl not needed
- Overtemp pump start (Top left stat) above 78° boost heat to accum
- Mid cylinder (bottom right stat) stoke alarm disconnected
20 Dec 2022
on vigas controller instuction P10 in the manual
- max 225°
- end 90°
- fan 3
- min fan3%
- need to disable accum return pump after a cold start, (takes all heat out if boiler can’t maintain temperatre due to high demand)
Nov 21st 2022
- Max water temp 75°
- Max Flue 220°
- Min flue now 90° (Shuts down boiler at the end of a cycle)
- Min Fan 3%
Top stat now 60° shut down earlier
Bottom stat is now new pump to return heat from Accumulator pump on below 59°
Thermostat Settings 24th Feb 2022
- Top cylinder 56° (controls final shutdown if boiler is out and no heat stored)
- Mid cylinder (burner control) 79°
- low cylinder(stoking needed alarm) 64°
- Mid cylinder (Accumulator circ pump on) 74°
- overtemp pump start (Top left stat) 78°
- Bottom cylinder (bottom right stat) 60°
On boiler control panel:
- Max water temp 75°
- Max Flue 220°
- Min flue 75° (Shuts down boiler at the end of a cycle)
- Min Fan 3%
- stopped rolling display
- brightness 65%
Energy – 2026
2026
Camelot forum\
MPAN Number
S 1 801 511 16 1002 1964 537
1st May 2024
Solax INV s/n U37EC6090GB076 14881AAC
Darfon Battery S/N EKEIA020050G22SJ002Y
25th Feb 2024
24th Jan 2024
spoke to shell and Octopus, no date yet
Tommy at electric store rang “give energy newgen3“
https://vrm.victronenergy.com/installation/62545/dashboard
Solax at Edmunson Electrical
Octopus and MCS cert: https://youtu.be/FSZhGxESm_Y
11 Jan 2024
emailed Oct to say we hadn’t asked to leave
Hi David,
Thank you for reaching out to us. I understand your disappointment regarding the confusion with your switch. I apologise for any inconvenience caused.
I want to assure you that we value you as a customer and we want to resolve this issue for you. I have taken note of your dissatisfaction and closed it as feedback log. Please be advised that messages you received were automated because of account attempting to switch without success.
The previous statement that you will be updated when migration happens is correct. After you switch I have left note on complaint that we would need to book engineer to visit you and install smart meters.
In the meantime, if you have any other questions or concerns, please don’t hesitate to let me know.
Kind regards,
Sanjin
Octopus Energy Ltd is a company registered in England and Wales. Registered number: 09263424. Registered office: UK House, 5th Floor, 164-182 Oxford Street, London, United Kingdom, W1D 1NN
On Fri, 19 Jan 2024 at 06:19, d.vidbooth@gmail.com wrote:
Good morning,
I am very disappointed that my application to switch over our supply has
gone wrong. You Said –“We’ve been notified by another supplier that you’ll be switching to them
from 18th January 2024. We’re sad to hear you’re leaving us, but of course
the choice is yours.”How did I choose to leave you?
But you never got on with the transfer, saying that the migration from
Shell Energy was going to be automatic and completed in late December.Where do we go from here? All I wanted was a smart meter that worked
properly and a flexible tariff.Please clarify the situation with me.
sincerely, David Booth
11 Jan 2024
17 Dec 2023
Gas calCalculator
9 Nov 2023
Sonoff power meter: https://www.amazon.co.uk/dp/B09XB3RZB9?th=1
Sonoff 4 channel:
Screwfix smart plug:
https://www.screwfix.com/p/tcp-wissinwuk-13a-smart-plug-white/231hk
Zappi: myenergi/Zappi
Octopus Site: https://octopus.energy/friend-referral/
Elec standing 49.77 day. 29.94 per unit
Gas standing 27.47 day. 7.51 per unit
Shell:
Elec standing 48.96 day. 31.16 per unit
Gas standing 27.72 day. 9.825p per unit
The system I had put in was 5.8 kw Solar panels Givenergy Hybrid 5.0 (gen 2) hybrid inverter (for AC and MPPT solar) with a Givenergy battery of 10.4kWh made up of two of their 5.2kWh units all in my loft. Then a Myenergi (Zappi) EV car charger and Myeddi hot water excess solar diverter. BTW because I was having more than 4kw installed I had to get permission from the Grid DNO (SP Energy for us) via a G99 form (the installer did the submission) and took 6 months to get an affirmative response.
Pob lwc.
Renewable energy products making eco energy easy | myenergi
Multi Award Winning Renewable Installers | Hafod Renewables (based in Llanelwy/St Asaph)
Solar Panel Installers – UK – Preston – NorthWest (in2gr8tedsolutions.co.uk) Edited by churchward
Google Sheets Chart editing:
Click icon on right of “Data range” and alter row numbers
Protected: Computers
Tram Road Junction Location
Tram Road JunctionSandpiper to Western isles 2024
Solar Storage 2024 – 2026
19th Mar 2025
Solar & Battery Installation– https://www.solarxpress.co.uk/
- 12 × 465W AIKO all-black panels with built-in optimisers (30-year warranty)
- 2 × 5kW Canadian Solar EP Cube batteries with built-in hybrid inverter
- Fully installed by our in-house team, including all warranties, certificates, and documentation
- £7,995 (reduced from £8,995)
Battery-Only Installation
- 10kWh Canadian Solar battery with built-in hybrid inverter – £3,995
- 15kWh Canadian Solar battery with built-in hybrid inverter – £5,500
- 20kWh Canadian Solar battery with built-in hybrid inverter – £6,500
6th Feb 2025
6th Feb 2025
We changed from Flexible Octopus to Octopus Go early January and started using off peak forced charging on the 8th Jan.
Our daytime rate is 25.57p/kWh (1.4p per unit dearer than 24.15p/kWh on flexible), but nearly all our consumption is now covered by the battery with a tiny bit of help from the Solar panels. The off peak charge costs 8.5 p per unit, so if we add on inverter losses, you could say it costs us 10p per unit.
This is a graph for yesterday (rubbish sunshine!) so we ended up using power from the grid again after about 7pm, unfortunately:
10th Jan 2025
signed up for Octo Go
24th Nov 2024
Gave up to Solax (0ld blog post)
Cerbo GX – victron
24th Nov 2024
nfinity Innovations Ltd,
Shed 7, Bocking Farm,
Cross Roads,
Keighley
BD22 9BG
info@infinityinnovations.co.uk
13th Nov 2024
This from yesterday was not very conclusive, I shall try again and next time take a normal photo of the boards from the same angle. Also I shall take the infra red thermometer to read the temp of the chips. The problem is, there are two layers of circuit board and its hard to get a clear picture of the back one whilst it is running. I shall also try and position the cross hairs of you camera on a warm chip to see what that comes up with. I think I am going to have to get a fresh unit in the end, but at least I’m not wasting solar power this week!
- 0sec Grid switched on
- 13 sec Click fron Panel input relay
- 25sec off/on/off again
- 46 sec Solar circuits fans start on top of inverter
- 1minute repeated clicks from central relay
- 1.22 RH fan on
- 1min 26sec heavy click from battery relay
- 1.30 green led on battery comes on
- 1min60 Another heavy battery relay click
- 2.14 battery led goes red
- 2.20 silence + no battery led
9th Nov 2024
Having failed to get this invertor talking to my Darfon BMS https://camelot-forum.co.uk/phpBB3/view … 480#p49480, I had 3,480 kWp solar fitted on a big shed (435W each x 8) last week and connected them in two strings 1 West and 1 East facing for comparison before potentially increasing the number of panels on the most effective side.
I have not yet got the remote monitoring sorted, but have got a LAN cable from my router connected to it in readiness. Not impressed with the SolaxCloud so far though.
The inverter display panel shows the voltages from the panels soon after booting up, but after a while the display freezes and is not responsive to button presses. I wonder if the thing is economically repairable or is it time to think about a replacement? Or is it just “finger trouble” on my part?
It seems to be fairly consistent, When the DC, the panels and lastly the mains are all connected, there are a few relay clicks from within, then the display buttons work and the setting can be changed after entering the Pass key and solar powers are shown on screen for half an hour or so, then it freezes up, often with the screen below:
1st Nov 2024
SK_SU3700E inverter and Darfon battery
cityplumbing as Midsummer have sold out
1st Nov 2024
3480W solars fitted big shed (435W each x 8)
12th Sept 2024
SK-SU-3700 U37EC6090GB076 Invertor serial
https://www.inbalance-energy.co.uk/Inverter-Faults/solax-power-inverter-faults-repairs.html
Manual page37 – menu structure
Manual page43 – work mode
Manual page44 – battery awaken y/n
7th Sept 2024
7th Sept 2024
Now looking into getting the invertor online and then buying a new battery,
I asked the question of the BMS repairer: “I wonder why this growatt battery says 57.4volts, yet the Solax inverter manual says it should stop charging at 53.5 and start again at a minimum 47v ? ” David
He replied:
So, this is one of the reasons that these batteries are not compatible with other brands of inverter.Thery work at a slightly higher voltage than other brand batteries.The only way you will get this system working is to add a Growatt SP2000 to charge the battery or replace the battery with one that is compatible with your Solax inverter.Kind regardsChris
31st Aug 2024
BMS first try: https://vimeo.com/1004760076
no voltage on the BMS output. The battery is showing 55.3 volts before the BMS
3 Aug 2024
Growatt Darfon GBLI5001 or GBLI2701 BMS boards
All of the packs should be within 0.2 volts of each other but ideally the closer the better. The BMS locks out if any of the packs is more than 0.2 volts higher or lower than the rest.
Also, if your SP settings are incorrect this can over time damage the battery.
Some installers change the settings to maximise the yield from the battery but this discharges the battery too low.
The settings should also allow the battery to be recharged to a minimum of 10% as soon as the PV is next active after a complete discharge regardless of home load
27 July 2024
charging bad cell pack at 4.2v constant voltage
We have partially stripped down the old Solax battery and I am starting to get a feel for the job ahead. Last night we took the one flat cell pack out and started charging it via its neighbour using a 12v lamp at 5pm.
I think this looks a similar battery: https://diysolarforum.com/threads/darfon-gro-watt-gbli-5001-battery-pack-worth-a-punt.24226/
a mention of mucky terminals being a problem later on in the thread
7pm – the two cells I am equalizing are still not settled (lamp dimly glowing) funny how it takes so long
9pm – 3.8v & 2.6v the lamp is out now, but i’ve disconnected them, don’t know if taking the good one down too low will damage it?
from this thread (the forum that I use)
a review on a different forumhttps://secondlifestorage.com/index.php?threads/boston-power-swing-5300-li-ion-cell-test.5188/
7 am next day – those two packs are now 3.9v & 1.8v, so I am beginning to suspect the BMS is faulty.
SK-SU3700 U37EC6090GB076 Invertor serial
Connection Step:
- Insert the RJ45 terminal on the current sensor into the CT port on the inverter.
- Place the current sensor around the phase wire L which the inverter is
connected. - Place the current sensor around the phase wire L to measure the current
going to or coming from the grid. - Make sure the current sensor is installed in the right direction: The arrow
on the current sensor must point to the public grid.
